Details
Don't worry, we get it...your training buddies all think you're a bit "particular". You may or may not have stockpiled your favorite grips just in case they ever get replaced by a new model. Perhaps your trailside toolbox would make a quality control engineer blush. Whatever the case, you won't find any judgement here.
Instead, the endlessly engineered S-Works Epic frameset is here for you to let your discerning tastes run wild. We sweated every last detail when designing the S-Works frame, from an endlessly refined layup schedule that re-examined every last ply of FACT 12m carbon to optimize weight savings and ride dynamics to the weight-shedding carbon shock link, all so that you focus on the rest, knowing that you're starting with the most capable canvas in the world.
A Smarter BRAIN
True to form, the latest Epic continues the tradition, taking advantage of the most efficient Brain suspension we've ever created to ensure it's always on a first-name-basis with fast.
Frame-Changer
Re-engineered hand-in-hand with the new Epic, the latest BRAIN design resets the expectation for efficiency, employing a new race-tuned pedaling platform to ensure every watt possible is translated into forward motion, while handily soaking up momentum-killing chatter and big hits alike—all more smoothly than ever.
Perfectly matched to the frame's BRAIN system, the S-Works Epic frameset's Position-Sensitive BRAIN fork benefits from RockShox's latest SID Ulitmate SL chassis for next-level steering stiffness that still manages to keep the gram count to a minimum.
- If speed could talk, it'd introduce itself as the all-new S-Works Epic frame. Offering 100-millimeters of brilliantly efficient Brain-controlled travel, the S-Work Epic increases rear-triangle stiffness for peerless power transfer, while the use of FACT 12m carbon, a dedicated layup, and a full carbon shock link also make it the lightest full-suspension frame we've ever created, all while offering the most capable handling in an Epic yet. Nice to meet you, speed.
- Pairing 100 millimeters of the most efficient travel on earth with RockShox's svelte-yet-stiff SID SL Ultimate chassis, the RockShox SID SL Ultimate BRAIN fork serves as the pinnacle of XC-race suspension perfection.
X-Small | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
Stack | 596mm | 586mm | 591mm | 605mm | 623mm |
Reach | 390mm | 415mm | 445mm | 470mm | 495mm |
Head Tube Length | 95mm | 95mm | 100mm | 115mm | 135mm |
Head Tube Angle | 67.5° | 67.5° | 67.5° | 67.5° | 67.5° |
BB Height | 314mm | 324mm | 324mm | 324mm | 324mm |
BB Drop | 58mm | 48mm | 48mm | 48mm | 48mm |
Trail | 106mm | 106mm | 106mm | 106mm | 106mm |
Fork Length, Full | 505mm | 505mm | 505mm | 505mm | 505mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 663mm | 687mm | 719mm | 750mm | 782mm |
Chainstay Length | 433mm | 433mm | 433mm | 433mm | 433mm |
Wheelbase | 1090mm | 1116mm | 1148mm | 1179mm | 1211mm |
Bike Standover Height | 740mm | 763mm | 766mm | 776mm | 788mm |
Seat Tube Length | 375mm | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 76.5° | 75.8° | 75.5° | 75.5° | 75.5° |
Top Tube Length, Horizontal | 533mm | 563mm | 598mm | 626mm | 656mm |
Inches | CM | Size |
---|---|---|
4'10"-5'1" | 148-155 | X-Small |
5'2"-5'5" | 158-165 | Small |
5'5"-5'10" | 165-178 | Medium |
5'10"-6'1" | 178-185 | Large |
6'1"-6'4" | 185-193 | X-Large |
6'3"-6'6" | 191-200 | XX-Large |
Due to supply-chain issues, Specs are subject to change without notice.
Specs
Frame | S-Works FACT 12m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel |
---|---|
Fork | RockShox SID SL ULTIMATE BRAIN, Top-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel |
Rear Shock | RockShox-Specialized BRAIN, Rx XC Tune, 5 Position Platform Adjust, Rebound Adjust, Integraded Extension, 265x52.5mm |
Seatpost | S-Works FACT carbon, 10mm offset, 30.9mm |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Gloss Fluid Chameleon/Satin Black / X-Small | 888818771752 | 70322-0001 | |
Gloss Fluid Chameleon/Satin Black / Small | 888818771660 | 70322-0002 | 210000030998 |
Gloss Fluid Chameleon/Satin Black / Medium | 888818773824 | 70322-0003 | 210000029658 |
Gloss Fluid Chameleon/Satin Black / Large | 888818773145 | 70322-0004 | 210000029334 |
Gloss Fluid Chameleon/Satin Black / X-Large | 888818772537 | 70322-0005 | 210000029353 |
Gloss Red Tint Fade Over Silver/Tarmac Black / X-Small | 888818618606 | 77620-0001 | |
Gloss Red Tint Fade Over Silver/Tarmac Black / Small | 888818618309 | 77620-0002 | |
Gloss Red Tint Fade Over Silver/Tarmac Black / Medium | 888818618781 | 77620-0003 | |
Gloss Red Tint Fade Over Silver/Tarmac Black / Large | 888818618569 | 77620-0004 | 210000029712 |
Gloss Red Tint Fade Over Silver/Tarmac Black / X-Large | 888818618545 | 77620-0005 | |
Satin Carbon/Color Run Blue Murano Pearl / X-Small | 888818773732 | 70322-0101 | |
Satin Carbon/Color Run Blue Murano Pearl / Small | 888818772568 | 70322-0102 | |
Satin Carbon/Color Run Blue Murano Pearl / Medium | 888818771646 | 70322-0103 | 210000030491 |
Satin Carbon/Color Run Blue Murano Pearl / Large | 888818772278 | 70322-0104 | 210000030492 |
Satin Carbon/Color Run Blue Murano Pearl / X-Large | 888818773176 | 70322-0105 | 210000031066 |
Satin Carbon/Lagoon Blue/Granite / X-Small | 888818771974 | 70322-0201 | |
Satin Carbon/Lagoon Blue/Granite / Small | 888818772483 | 70322-0202 | 210000031135 |
Satin Carbon/Lagoon Blue/Granite / Medium | 888818772926 | 70322-0203 | 210000029708 |
Satin Carbon/Lagoon Blue/Granite / Large | 888818772162 | 70322-0204 | 210000029709 |
Satin Carbon/Lagoon Blue/Granite / X-Large | 888818773671 | 70322-0205 |
